Car Body Design and Aerodynamics Notes
Politecnico di Torino automotive engineering (ingegneria dell'autoveicolo) Curriculum vehicle system development 2025
Nessun voto ancora
Stai vedendo l'anteprima delle prime pagine. Sblocca tutte le pagine con l'abbonamento.
Di cosa parla
- Car Body Design - Packaging & Ergonomics:
- Focuses on optimizing interior space for safety, comfort, and control accessibility.
- Utilizes anthropometry (statistical body measurements, percentiles) to model drivers.
- Emphasizes proper backbone posture and uses manikin models (SAE J826) for seating and eye ellipses (SAE J1052) for visibility.
- Outlines pedal configurations, considering heel point (HP) and H-point.
- Structural Configuration:
- Compares body-on-frame (modularity, NVH isolation) and unibody (lighter, lower CG, integrated structure) designs.
- Identifies key structural members: longitudinal beams, cross beams, sills, and pillars (A, B, C).
- Discusses cross-section designs for stiffness and to prevent rust.
- Explores suspension load distribution and the role of cross members.
- Structural Analysis:
- Applies Bredt equations for calculating torsional stiffness in thin-walled, closed cross-sections.
- Examines global (bending) and local (folding) instability for energy absorption.
- Illustrates plastic deformation types: concertina (extensional) and diamond (inextensional) modes.
- Discusses the use of structural foams for energy absorption.
- Pedestrian Impact:
- Defines critical impact zones (leg, hip, head) and uses specialized impactors for testing.
- Outlines legislative test procedures for impact speed, angle, and critical points.
- Engine Suspension (NVH - Noise, Vibration, Harshness):
- Ensures torque transmission, engine support, and vibration attenuation.
- Explores different mount types: rubber (viscoelastic, non-linear), hydraulic (variable damping), and magnetorheologic (magnetic field-controlled viscosity).
- Details mount configurations (3 mounts, CG alignment, single rod) for optimal performance.
- Analyzes dynamic excitations from road, wheels, and powertrain using Power Spectrum Density (PSD).
- Aerodynamics Principles & Characteristics:
- Covers Bernoulli's principle (faster flow = lower pressure), Coandă effect (flow attachment), and Magnus effect (spinning object creates force).
- Defines flow characteristics: density, viscosity, Reynolds and Mach numbers.
- Explains boundary layer phenomena: laminar vs. turbulent flow, and boundary layer separation (leading to drag).
- Classifies bodies as aerodynamic or bluff, relating shape to dominant drag type.
- Computational Fluid Dynamics (CFD):
- Utilizes Navier-Stokes equations for mass, momentum, and energy conservation.
- Details the CFD process from CAD to meshing, solver execution, and post-processing.
- Addresses mesh quality factors (skewness, smoothness, aspect ratio) and turbulence modeling (DNS, LES, RANS).
- Aerodynamic Applications:
- Focuses on drag reduction strategies for the front profile, windscreen, A-pillar, rear end, and underbody.
- Discusses air dams, rockers, rear-view mirrors, and spoilers for managing airflow.
- Explores the aerodynamic impact of wheels and wheelhouses.
- Addresses cooling drag, active grille shutters, and the comprehensive design of vehicle underbodies.
